⚠ Also required — not included: L-Track not included
Full Feature Details
THE RETRACTOR THAT CHANGED THE INDUSTRY
The QRT Deluxe is the original self-locking and self-tensioning retractable system. The Deluxe features dual tightening knobs and is considered the industry standard.
Feature
Description
DUAL TIGHTENING KNOBS
Provides additional tensioning if needed.
AUTOMATIC, SELF-LOCKING
Allows easy, one-handed hook-up of wheelchairs.
SELF-TENSIONING
No manual tensioning required. Retractors automatically take up ‘slack’ to ensure wheelchair passenger is always secured.
POSITIVE LOCK INDICATOR
Patented feature clearly indicates when fitting is locked in anchorage (L-track application only).
INTERCHANGEABLE
Eliminates confusion; no right, left, front or rear locations.
LOW PROFILE & COMPACT
No mounting bracket allows retractors to fit under most footrests.
ACCOMMODATES LARGER WHEELCHAIRS
Reduced overall retractor length leaves more room for wheelchairs.
UNIVERSAL DESIGN
Accommodates virtually all wheelchair designs, including scooters.
ULTRA-DURABLE
Constructed from hardened steel and coated in zinc for maximum corrosion resistance.
J-HOOK
Reduces twisting of belts and ensures proper securement with a quarter turn accommodating virtually all wheelchair designs.
FOOT RELEASE LEVER -
Easy release eliminates the need to bend down.
Vehicle Applications
🚐 Wheelchair-Accessible Van (WAV)🚌 Paratransit / Minibus🚑 Non-Emergency Medical Transport (NEMT)🚌 School Bus🚐 Sprinter / Transit Van🚆 Rail / Community Transit
Standards & Compliance
SAE J2249Wheelchair Tie-Down Systems for Motor Vehicles
ISO 10542Wheelchairs — Tie-Down & Occupant Restraint Systems
FMVSS 209Seat Belt Assemblies
FMVSS 210Seat Belt Assembly Anchorages
FMVSS 222School Bus Passenger Seating & Crash Protection
FMVSS 302Flammability of Interior Materials
CSA Z605Wheelchair Securement in Motor Vehicles (Canada)
ℹ️ ADA Compliance Note: This product is designed for use in ADA-accessible transportation applications. Verify that installation meets applicable ADA requirements for your specific vehicle type and use.
🛡 Warranty: 3-year limited. * Registration required at qstraint.com for full coverage. Without registration, 1-year limited applies.
⚠ Warranty terms should be verified directly with the manufacturer.
⚠ California Prop 65 Warning: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. See qstraint.com/prop-65
Does this kit include everything I need for one wheelchair position? +
A complete wheelchair tie-down and occupant restraint system — often called a 4-point securement system — has three primary components: floor anchorages (L-Track rail and floor pockets), wheelchair securement retractors (4-point tie-downs), and an occupant restraint (lap and shoulder belt). See the What's Included section for exactly what this kit contains and what may need to be purchased separately.
Do I need to buy floor anchors separately? +
Check the What's Included section. If L-Track rail or floor pockets are not listed, they need to be purchased separately. Your vehicle may already have floor anchorage installed — check before ordering.
Is professional installation required? +
The retractors connect to existing floor anchorage and require no special tools for daily use. Floor anchorage components must be installed by a qualified WAV modifier.
Can I mix brands within the same vehicle? +
We do not recommend mixing brands within the same 4-point wheelchair position. All four retractors at each position should be the same brand and series for system-level compatibility and compliance.
Do I need to register this product for the full warranty? +
Registration at qstraint.com is required for full warranty coverage.
What vehicle types is this kit designed for? +
See the Vehicle Applications section. Contact us to confirm suitability for your specific vehicle make and model.
Specifications
Specification
Detail
Brand
Q'Straint
SKU
Q-8101-L
Price
$548.00 — price shown is per kit
Shipping
Free Shipping
Warranty
3-year limited
Use / Installation
Retractors require no special installation for daily use. Floor anchorage components require professional installation by a qualified WAV modifier.
